UV Source
Ozone-free medium-pressure mercury-vapor lamp.
Exposure
Rotating specimen drum supports more uniform irradiation.
Control
Test duration and chamber temperature are regulated throughout the cycle.
NF-5 UV Radiation Resistance Tester
Controlled UV Irradiation Testing for Laminated Glass
UV Irradiation Test System for Laminated Glass
The NF-5 provides controlled ultraviolet irradiation for evaluating laminated glass after prolonged exposure, with regulated temperature, timed operation and rotating sample positioning for uniform irradiation.
Exposure
0–300 h
Temperature
Ambient to 100°C
Sample Drum
1–5 rpm
System Overview
Controlled UV Exposure for Laminated Glass Evaluation
Technical Architecture
Core System Components
- Power supply
- UV lamp
- Rotating sample drum
- Motor and reduction drive
- Control circuit
Test Principle
Evaluate Glass Before and After UV Exposure
Initial Evaluation
The specimen is first evaluated for light transmittance before irradiation where required.
Controlled Exposure
The specimen is exposed inside the NF-5 for the specified test duration and temperature.
Post-Exposure Review
After irradiation, the specimen can be evaluated again for visible discoloration and reduction in light transmittance.
Key Features
Laboratory Configuration for Controlled UV Irradiation
Controlled UV Irradiation
Ozone-free quartz tubular medium-pressure mercury-vapor arc lamp.
Rotating Sample Drum
Sample drum rotates from 1–5 rpm to support more uniform irradiation.
Temperature Control
Controlled chamber temperature from ambient temperature to 100°C.
Extended Exposure Testing
Programmable exposure duration from 0–300 hours.
Laminated Glass Testing
Suitable for automotive, architectural and fire-resistant laminated glass specimens.
Automatic End-of-Cycle Stop
When the preset irradiation time is reached, operating functions stop while the main power remains in standby.
Technical Specifications
NF-5 Measurement and Instrument Data
Irradiation source
Ozone-free quartz tubular medium-pressure mercury-vapor arc lamp
Lamp length
360 mm
Lamp diameter
9.5 mm
Arc length
300 ± 14 mm
Power supply
220 V
Working power
750 ± 50 W
Starting peak voltage
1100 V
Working voltage
500 ± 50 V
Specimen size
76 × 300 mm
Specimen thickness
6–30 mm
Sample drum speed
1–5 rpm
Temperature control range
Ambient temperature to 100°C
Time setting range
0–300 h
Timing accuracy
0.1 s
Test Workflow
Controlled Exposure Operation
- Prepare and clean the specimen.
- Measure initial light transmittance where required.
- Place specimens in the rotating sample drum.
- Set irradiation time and test temperature.
- Start the UV source, drum rotation and temperature control.
- Run the exposure cycle.
- Remove specimens after completion and evaluate post-exposure condition and transmittance.
Applications
Laminated Glass UV Resistance Testing
- Automotive laminated glass
- Architectural laminated glass
- Fire-resistant laminated glass
- Laminated glass quality-control laboratories
- Deep-processing glass manufacturers
- Quality inspection and testing laboratories
Request Review
Discuss NF-5 for Laminated Glass Testing
Share the glass type, intended test workflow and evaluation requirement. LUARI can review whether NF-5 is suitable for the application.
