Repeatability ≤ 1° • Automatic Reporting • 2-Year Data Storage • Operator Independent
Optical Distortion and Visual Detection
Zebra angle measurement
Fully Automated · Repeatability ≤ 1° · Digital & Traceable results
Edge-light detection
Uniform illumination · High-contrast defects · Stable inspection
Spectral and Optical Transmission Measurement
Spectral transmittance measurement
(for photovoltaic and processed glass)
380–1100 nm spectral range · AM1.5 & D65 support
Transmission and haze measurement
Transmission & haze · high accuracy · for coated and PV glass
Without historical records, quality decisions become difficult to compare across shifts, operators and production campaigns.
Measurement validation using real production samples to ensure alignment with application requirements
Example of structured measurement report generated by the system, aligned with international standards
Automatic report generation with time-based storage for full traceability
Integration into production lines for continuous quality control
Repeatable results that support both quality control and production improvement.
Optical Metrology Implementation Workflow
Definition of measurement scope, including zebra angle, optical distortion or spectral transmittance, aligned with applicable standards.
Configuration and calibration of measurement systems to ensure objective, repeatable and traceable data output.
.png)
System installation and validation through reference samples, ensuring consistency with laboratory or production benchmarks.
.png)
Continuous calibration support and data monitoring to maintain long-term measurement reliability.
Submit your application details — our engineering team will review and recommend a suitable optical measurement solution.
Zebra Angle Measurement System (FZT-2)
Automated optical distortion analysis for production and laboratory environments.
Objective, repeatable and traceable measurement — eliminating operator dependency.
Used across 100+ production lines and certified laboratories worldwide
